Image is a representation of this item. Actual item may vary.
Part Number:
DRP-35008-6

35008-6 Diamond Pistons Ford 3.5L Ecoboost Forged Dish 93mm Bore

Fits Ford 3.5L 6 Cylinder Ecoboost, Bore 93mm, Stroke 3.4133, Rod Length 6.0137, Dish -8.8cc, Set of 6 Pistons and Rings

$1,062.01
View Similar Items
⚠ PROP 65 WARNING
⚠ WARNING: This product can expose you to chemicals, which are known to the State of California to cause cancer. Please contact us to obtain a list of harmful chemicals. For more information, go to www.P65Warnings.ca.gov.
Diamond Pistons are some of the best aftermarket pistons on the market. Trust your new engine with a set of Diamond Pistons
  • Piston Crowns designed to work with OEM direct injection
  • Offset wrist pins provide quiet operation
  • Moly skirt coating for friction loss
  • 2618 forging for high hp/ boosted applications
  • Standard 1.5mm x 1.5mm x 3mm ring package
  • Premium 8620 wrist pins are included
  • Compression ratio figured for 3.641 x .040 head gasket
  • Top ring down from piston crown .300"
  • Vavle pocket depth = .090" intake and .000" exhaust
  • Oversize valve pocket for larger than stock valves

    Compression Ratio with Factory cc: 9.0:1
    No advertised piston weight
  • More Information
    CNC Part Number DRP-35008-6
    Price $1,062.01
    Manufacturer's Part Number 35008-6
    Brands Diamond
    Part Types Engine Piston
    Departments Parts
    Vehicle Make Ford Ecoboost
    Bore Size 93.00mm
    Crankshaft Stroke 3.4133
    Rod Length 6.0137
    Piston Type Dish
    Compression Height 1.240
    Piston Material 2618 Forged
    Piston Ring Size 1.5 1.5 3.0mm
    Wrist Pin Size 0.905
    Custom Notices ⚠ PROP 65 WARNING
