11661 Diamond Pistons Chevy 350 Forged Dome 4.030 Bore

SB Chevy 350, Bore 4.030, Stroke 3.625, Rod Length 5.700, Dome 11cc, Set of 8 Pistons, Made to order

$1,207.44

View Similar Items

⚠ PROP 65 WARNING

⚠ WARNING: This product can expose you to chemicals, which are known to the State of California to cause cancer. Please contact us to obtain a list of harmful chemicals. For more information, go to www.P65Warnings.ca.gov.

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Image is a representation of this item. Actual item may vary.

Description

Diamond Street/Strip Small Block Chevy 23 Degree Dome Pistons are great circle track or street/strip shelf pistons. Designed for N/A or small nitrous applications. They fit most 23 Degree cylinder heads. Ratios are configured @ 9.000" deck height. Standard 1/16" x 1/16" x 3/16" ring package (Rings not Included). Premium 8620 wrist pins included. Gasket volume = 9.1cc, top ring down= .180" @ 1.000" to 1.187"; .210" @ 1.218" to 1.550", valve relief depths = .285" intake and .200" exhaust.

Compression Ratio with 64cc Heads 13.1:1
Compression Ratio with 70cc Heads 12.0:1
No advertised piston weight
Made to order

Specifications

More Information
CNC Part Number	DRP-11661
Price	$1,207.44
Sold As	Set
Manufacturer's Part Number	11661
Brands	Diamond
Part Types	Engine Piston
Departments	Parts
Vehicle Make	Chevy SB
Bore Size	4.030
Crankshaft Stroke	3.625
Rod Length	5.700
Piston Type	Dome
Compression Height	1.488
Piston Material	4032 Forged
Piston Ring Size	1/16 1/16 3/16
Wrist Pin Size	0.927
Custom Notices	⚠ PROP 65 WARNING
