CNC LS 6.0L 408 Short Block, Molnar Crank, Diamond 9.5 Turbo / Nitrous Pistons

CNC-Motorsports LS 6.0L short blocks have quickly raised the bar to a new level in offering high quality short blocks at an affordable price. Our short blocks have become a huge hit among racers and performance enthusiast all over the world. We have the ability to custom build you just about any combination the way you want it. All our short blocks are 100% machined, CNC Machined and blue-printed to our race wining specs. We "Never" cut corners to lessen the price.

Core GEN IV, 6.0L, LY6, L96 Cast Iron Block

New Molnar 4340 forged steel crankshaft (4.000 Stroke) center counterweight **Internal Balance**

New Molnar H-Beam connecting rods bushed fit pins, ARP 8740 Bolts

Diamond LS2K forged pistons, .225 wall wrist pins (*Fits all 15 degree LS Heads L92*)

Steel Piston ring set, Steel top ring, Napier second ring, with 3.0mm oil rings for power adders

H series race rod and main Bearings

Performance cam bearings

Comp Cams freeze plug kit

ARP main studs

Compression Ratio with 62cc head 10.0:1 (Turbo / Nitrous)

Compression Ratio with 70cc head 9.5:1 (Turbo / Nitrous )

Rated to support 1300 Horsepower

Note: *Camshaft & timing chain not included**

*Professionally Machined, Balanced, Assembled and blue printed in house by CNC-Motorsports. Balance card and blue print sheet will be provided to the customer. All short blocks are standard bore unless otherwise noted. We can custom build any short block assembly to meet your needs.
