Comp Cams 26911-16 Valve Springs, Hydraulic Roller Spring .650 Lift

Valve Spring, Single Spring / Damper, 410 lb/in Spring Rate, 1.140 in Coil Bind, 1.486 in OD, Set of 16, Replaces 911-16, 926-16

$121.95

View Similar Items

⚠ PROP 65 WARNING

⚠ WARNING: This product can expose you to chemicals, which are known to the State of California to cause cancer. Please contact us to obtain a list of harmful chemicals. For more information, go to www.P65Warnings.ca.gov.

Description

The new Comp Cams 26911 valve springs allows more lift than either spring it replaced. This spring is a great choice for hydraulic roller applications where you want a single spring and have a 1.486" OD pocket.

Single Spring with Damper
Spring Rate 410 lb/in
Coil Bind Height 1.14 in
Installed Height 1.85 in
Outside Diameter of Outer Spring 1.486 in
Maximum Valve Lift 0.650 in
Seat Load (LBS) 120 lbs
Seat Load At (in) 1.85 in
Open Load (LBS) 387 lbs
Open Load At (in) 1.2 in
Material Steel
Quantity Set of 16

Specifications

More Information
CNC Part Number	CCA-26911-16
Price	$121.95
Manufacturer's Part Number	26911-16
Brands	Comp Cams
Part Types	Engine Valve Spring, Hardware
Departments	Parts
Coil Bind	1.140
Installed Height	1.850"
Number of Springs	Single
Outer Spring Outer Diameter	1.486
Spring Rate (LBS./IN.)	410
