Comp Cams 26924-16 Valve Springs, Flat Tappet or Hydraulic Roller

Valve Spring, Dual Spring / Damper, 376 lb/in Spring Rate, 1.040 in Coil Bind, 1.519 in OD, Set of 16, Replaces 924-16, 925-16, 950-16, 977-16

$193.95

View Similar Items

⚠ PROP 65 WARNING

⚠ WARNING: This product can expose you to chemicals, which are known to the State of California to cause cancer. Please contact us to obtain a list of harmful chemicals. For more information, go to www.P65Warnings.ca.gov.

Description

Comps new 26924 was a total redesign with a new modern approach. This new design can allow up to .750 lift at 1.850 installed height hydraulic roller applications. This spring will also work in flat tappet applications under .600 lift.

Dual Spring with Damper
Spring Rate 376 lb/in
Coil Bind Height 1.040 in
Installed Height 1.900 in
Outside Diameter of Outer Spring 1.519 in
Inside Diameter of Outer Spring 1.150 in
Inside Diameter of Inner Spring 0.779 in
Maximum Valve Lift 0.750 in
Seat Load (LBS) 120 lbs
Seat Load At (in) 1.900 in
Open Load (LBS) 421 lbs
Open Load At (in) 1.100 in
Quantity Set of 16

Specifications

More Information
CNC Part Number	CCA-26924-16
Price	$193.95
Manufacturer's Part Number	26924-16
Brands	Comp Cams
Part Types	Engine Valve Spring, Hardware
Departments	Parts
Coil Bind	1.040
Installed Height	1.900
Number of Springs	Dual
Outer Spring Outer Diameter	1.519
Spring Rate (LBS./IN.)	376
