Image is a representation of this item. Actual item may vary.
Part Number:
HOL-300-295BK

Holley 300-295BK Single Plane 4500 Intake Manifold - Black Finish

Single Plane 4500 Carbureted Split-Design Race Intake Manifold - GM LS1/LS2/LS6
Fits GM LS1/LS2/LS6 - Carbureted with Black Finish

Part #
 300-295BK

$849.95
View Similar Items
⚠ PROP 65 WARNING
⚠ WARNING: This product can expose you to chemicals, which are known to the State of California to cause cancer. Please contact us to obtain a list of harmful chemicals. For more information, go to www.P65Warnings.ca.gov.
The new Holley Single-Plane Race intake manifold is designed with maximum performance in mind. Featured is a two-piece split design that provides access for all levels of porting and modification. With shoulder bolt locators and O-ring seal, disassembly & reassembly is simple and precise. The manifold with AN-8 fuel rails fits GM LS Gen III engines with cathedral port heads and has a 4500 Dominator style carb flange for carburetors, EFI throttle bodies, or EFI throttle body elbows, and is configured with a LS MAP sensor port along with other NPT plenum vacuum or air-temp sensor ports. The LS Race single-plane intake manifold is designed for hi-performance/racing engine applications, 5.3 to 6.2+ liter displacements, N/A or with power adders. The large volume 4500 plenum and optimized runners provide airflow potential for Hi-RPM engines with max power at 7500-8000+ RPM. Features: Maximum performance 4500 Dominator flange race design with hood clearance consideration Lighter than other split race intakes Split feature making porting efforts easy! 33 to 50% the price of other split race intakes Captured O-ring seals at head ports and plenum split Vacuum Port options include (2) 1/8, (1) 1/4, and (1) 3/8, NPT ports at the carb flange Two versions available: EFI type - Billet Fuel Rails and rail mounting hardware included, or Carbureted / Sniper EFI 4500 TBI style
More Information
CNC Part Number HOL-300-295BK
Price $849.95
Manufacturer's Part Number 300-295BK
Brands Holley
Part Types Intake Manifold
Departments Parts
Vehicle Make GM LS
Intake Manifolds & Accessories Intake Manifolds
Manifold Base 4500/Dominator
Manifold Series Sniper
Intake Finish Black
Manifold Type Single Plane
Custom Notices ⚠ PROP 65 WARNING
