Part Number:
JE-187698

JE Pistons 187698 Forged Ultra-Light GP 4.030 Bore

JE Pistons, SBC, 357, Bore 4.030, Stroke 3.500, Rod Length 6.000, Flat Top -4.0cc, 352 Grams, Set of 8

Special Price $1,059.29 Regular Price $1,176.99
View Similar Items
⚠ PROP 65 WARNING
⚠ WARNING: This product can expose you to chemicals, which are known to the State of California to cause cancer. Please contact us to obtain a list of harmful chemicals. For more information, go to www.P65Warnings.ca.gov.
JE Pistons are machined by the most advanced CNC machining technologies available. JE forged Pistons are trusted by racers and engine builds for dependability. The #1 choice for Late Model Stock engine builders. Rated to 400 hp these pistons feature a contoured bottom band and a 2.400 length pin for maximum weight savings. Precision CNC machined .043, .043, 3mm back cut ring grooves. Footnote X parts are rated to 500hp, they will work with 21º angle milled heads and have deeper valve pockets.

Includes:
  • Pin #927-2400-13-51C (103g)
  • Wire lock #927-073-MW
  • Lateral gas ports
  • Accumulator Groove
  • Contact Reduction Grooves
  • Double Pin Oilers

    Compression Ratio:
  • 58cc 11.3:1
  • 64cc 10.5:1
  • 76cc 9.2:1
  • More Information
    CNC Part Number JE-187698
    Price $1,176.99
    Manufacturer's Part Number 187698
    Brands JE
    Part Types Engine Piston
    Departments Parts
    Vehicle Make Chevy SB
    Bore Size 4.030
    Crankshaft Stroke 3.500
    Rod Length 6.000
    Piston Type Flat Top
    Compression Height 1.250
    Piston Material 2618 Forged
    Piston Ring Size .043 .043 3.0mm
    Wrist Pin Size 0.927
    Custom Notices ⚠ PROP 65 WARNING
