Image is a representation of this item. Actual item may vary.
Part Number:
JES-KBD-31500

KBD-31500 Jesel Small Block Chevy Belt Drive

SB Chevy, Dart, Brodix +.391 Cam

Special Price $1,601.78 Regular Price $1,695.00
View Similar Items
⚠ PROP 65 WARNING
⚠ WARNING: This product can expose you to chemicals, which are known to the State of California to cause cancer. Please contact us to obtain a list of harmful chemicals. For more information, go to www.P65Warnings.ca.gov.
Innovation is at the forefront of any product produced by Jesel and that’s why our Camshaft Belt Drive Systems are one of the most sought after components in the racing industry today. From the first prototype camshaft belt drive ever manufactured by Dan Jesel back in 1982 to the sleekness of today’s CNC machined pieces, Jesel Camshaft Belt Drives continue to lead the industry as the premiere camshaft belt drive assembly. In the never ending quest for more horsepower, engine builders in the 1970’s began using larger cam lobes which in turn required stiffer springs. The stiffer springs allowed the engine to turn more rpm, but eventually became too much for a timing chain to handle. At the time, gear drives were the only solution, but they bring with them their own set of problems. Gear drives transfer a tremendous amount of crankshaft harmonics to the valvetrain, not to mention taking incredible amounts of horsepower to drive. As necessity is the birth of most components in high performance engines, the Jesel Camshaft Belt Drive was created to solve these problems.

Recognizing the need for improvement, Dan Jesel did what he does best. Using internal cam belt assemblies as a blueprint, Dan engineered a system to externally adapt this technology to a small block Chevrolet. After sourcing a belt and gathering material, Dan went to work manufacturing the prototype pieces and in conjunction with a local engine builder successfully built and tested the drive on a NHRA Competition Eliminator engine. The results were more than impressive and the dyno numbers proved it.

Today, all Jesel Belt Drives feature extremely accurate externally adjustable cam timing to fine tune the engines power curve. The camshaft can be changed by simply removing the upper pulley and cam seal plate. Teflon® coated cam and crank seals insure proper oil and vacuum sealing. The Gates High Torq Drive™ belts are engineered to handle well over 1200 lbs of spring pressure and are custom made to Jesel specs to insure the proper belt tension. And on certain applications, we have cam adapter assemblies capable of reducing camshaft endplay down to as low as .001”.

To date, Jesel has engineered an arsenal of over 40 belt drive assemblies. So, whether you’re on a six second pass down a quarter mile drag strip, racing in a 24 hour endurance race or just taking a trip down to the local car show, you can be assured that the components controlling your cam timing are of the highest standards and machined to exacting tolerances.

FEATURES:
  • Patented High Torq Drive™ reinforced belt operates dry and spins with less friction than timing chains or gear drives and also absorbs harmonics.
  • Cam timing adjustment is made externally providing the easiest and most accurate tuning available.
  • Teflon® coated high vacuum cam and crank seals.
  • Crank Pulley is heat-treated steel and incorporates a High Torq Drive™ tooth configuration.
  • Cam timing is externally adjustable
  • Kit hardware is all Grade 8 Allen and Torx™ head design.
  • 2 Piece Upper Pulley Design is infinitely adjustable ±10°.
  • Solid Upper Pulley Design is adjustable ±8° in 2° increments.
  • Hard coated Billet Aluminum Upper Pulley features patented High Torq Drive™ tooth configuration.
  • Accessories available to run distributor drives, fuel pumps or oil pumps off front of cam.
  • More Information
    CNC Part Number JES-KBD-31500
    Price $1,695.00
    Manufacturer's Part Number KBD-31500
    Brands Jesel
    Part Types Timing Belt Drive Kit
    Departments Parts
    Vehicle Make Chevy SB
    Upper Pulley 2 Piece
    Custom Notices ⚠ PROP 65 WARNING
