Part Number:
MAH-197713965

Mahle Pistons 197713965 Dish Ford ST 88.0mm Bore

Mahle Pistons, Ford Focus ST EcoBoost 2.0L, Bore 88.0mm, Stroke 83.1mm, Rod Length 155.87mm, Dish -7cc, 361 Grams Advertised Weight, Set of 4 Pistons and Rings Included.

Special Price $821.17 Regular Price $892.58
View Similar Items
⚠ PROP 65 WARNING
⚠ WARNING: This product can expose you to chemicals, which are known to the State of California to cause cancer. Please contact us to obtain a list of harmful chemicals. For more information, go to www.P65Warnings.ca.gov.
Mahle pistons were designed as a completely finished drop in forged piston assembly. Other than filling the included performance piston ring set, everything is done for you. Mahle has over 80 plus years of piston manufacturing making pistons from OEM to formula 1 racing. Mahle uses only the best technology to make these pistons. Mahle pistons come standard with anti-friction skirt coating for reduced drag. Forged from 4032 low expansion aluminum alloy for high strength and reduced piston to wall clearance. Forced Pin Oiler is used for increased wrist pin lubrication. Pin bores are CNC precision-machined. 22.5mm High-Quality Steel Wrist Pin (98g), Performance 1.2, 1.2, 2.8mm performance ring set, steel nitrided top ring, and Race Proven Round Wire Locks are included.

Compression Ratio with 43cc Heads 9.4:1.
More Information
CNC Part Number MAH-197713965
Price $892.58
Manufacturer's Part Number 197713965
Brands Mahle
Part Types Engine Piston
Departments Parts
Vehicle Make Ford 2.0L
Bore Size 88.00mm
Crankshaft Stroke 3.272
Rod Length 6.137
Piston Type Dish
Compression Height 1.291
Piston Material 4032 Forged
Piston Ring Size 1.2 1.2 2.8mm
Wrist Pin Size 22.5mm
