Image is a representation of this item. Actual item may vary.
Part Number:
MAN-598070CE-8

Manley Pistons 598070CE-8, 11.0:1 Dome, 3.700 Bore

Ford Coyote 5.0L Gen I/II DOHC 4 Valve (2011-2017), Bore 3.700, Compression Ratio 11.0:1, Dome +3.75cc, Grams 398, Set of 8

$1,136.20
View Similar Items
⚠ PROP 65 WARNING
⚠ WARNING: This product can expose you to chemicals, which are known to the State of California to cause cancer. Please contact us to obtain a list of harmful chemicals. For more information, go to www.P65Warnings.ca.gov.

Manley Platinum Ford Pistons are forged from 2618 high strength material lightweight design.
Offset wrist pin designed for quiet start-ups, mimics OEM design.
Features a perfect ring groove to skirt squareness, and a pressure balance groove.
2.500" x .210 length wall 9310 alloy included with round wire locks.
1.2 x 1.2 x 3mm ring package. *rings not included*
Will accommodate +1mm valve sizes.
.200 deck thickness, .225" down top ring
More Information
CNC Part Number MAN-598070CE-8
Price $1,136.20
Manufacturer's Part Number 598070CE-8
Brands Manley
Part Types Engine Piston
Departments Parts
Vehicle Make Ford Coyote
Bore Size 3.700
Crankshaft Stroke 3.650
Rod Length 5.933
Piston Type Dome
Compression Height 1.165
Piston Material 2618 Forged
Piston Ring Size 1.2 1.2 3.0mm
Custom Notices ⚠ PROP 65 WARNING
