JE Pistons 207421 Forged S/B Chrysler Flat Top 4.070 Bore

JE Pistons, SBC 416, Bore 4.070, Stroke 4.000, Rod Length 6.125, Flat Top -6.8cc, 489 Grams, Set of 8

$1,096.99

View Similar Items

⚠ PROP 65 WARNING

⚠ WARNING: This product can expose you to chemicals, which are known to the State of California to cause cancer. Please contact us to obtain a list of harmful chemicals. For more information, go to www.P65Warnings.ca.gov.

Skip to the end of the images gallery

Skip to the beginning of the images gallery

Image is a representation of this item. Actual item may vary.

Description

JE small block Chrysler pistons are machined to accommodate large valves and long duration, tight lobe separation cams these pistons are machined for 1/16, 1/16, 3/16 rings, and .927" diameter wrist pins. Pin upgrade recommended above 700hp.

Includes:

Pin #927-2750-15-51S (130g)

Double spiro locks (#927-042-CS)

Compression Ratio:

60cc 12.3:1

65cc 11.6:1

70cc 10.9:1
Note: *Made to Order.*

Specifications

More Information
CNC Part Number	JE-207421
Price	$1,096.99
Sold As	Set
Manufacturer's Part Number	207421
Brands	JE
Part Types	Engine Piston
Departments	Parts
Vehicle Make	Chrysler SB
Bore Size	4.070
Crankshaft Stroke	4.000
Rod Length	6.125
Piston Type	Flat Top
Compression Height	1.460
Piston Material	2618 Forged
Piston Ring Size	1/16 1/16 3/16
Wrist Pin Size	0.927
Custom Notices	⚠ PROP 65 WARNING
